Honda CB72, CR72 Self-generating CDI Ignition System - STK-172

Honda CB72, CR72 Self-generating CDI Ignition System - STK-172
Honda CB72, CR72 Self-generating CDI Ignition System - (STK-172)Timing marks - (STK-172)Pre-programmed Advance Curve - (STK-172)CDI with adjustable rev limiter

Price (excl. vat): 354.00 / 414.18
(424.80 / 497.02 Including VAT at 20%)

Many of these items are made to order.
You will be advised on any delay.

Race Ignition Kit Fits:


NOTE: We can aslo supply a system to fit the original CR72 race bike, this has no starter mechanism therefore a much shorter crankshaft.

  • Self generating (no battery required).
  • High performance cdi ignition system for twin cylinder 4 stroke with a 180 degree crank.
  • Low inertia rotor improves engine pick-up. Independent digital CDI (supplied with a user adjustable rev limiter 7000-13000rpm), and HTcoils for each cylinder, are programmed with an optimum advance curve specifically for this bike.
  • Maximum advance curve of this system is 35 degrees, so static timing is typically set to 10 degrees to give a total recommended advance of 45 degrees.
  • See fitting instructions for more information.
  • Manufactured in the UK.

In common with other suppliers we are unable to offer warranty for electrical components used for racing.

Click the following link to download fitting instructions:
Download Instructions


  • Road bike components - one year from the date of purchase
  • Off-road bike components - six months from the date of purchase
  • Race bike components - no warranty in line with industry practice
  • Any warranty does not cover defects due to abuse, misuse, improper installation or modification.


If any items were damaged in transit, we ask that you report it to us within 7 working days. On their return they can be replaced or a refund issued via your original payment method.

Faulty on arrival

If your items are faulty on arrival, you should inform us within 14 days of delivery. Items should be returned in their original packaging when possible with a copy of original documentation. Once we have verified the fault, we will issue a replacement or full refund to you via your original payment method.

Items faulty in warranty period

If any of your purchases develop a fault within its warranty period it will need to be returned. Once the fault has been verified, a repair or exchange of goods will be issued. If goods are found to be in good working order a testing/administration charge of 15 + VAT and return postage will be made to the customer.

Items ordered in error

If an item has been ordered in error, you should inform us within 14 days of delivery. We will not accept returned goods without prior consent except under guarantee. A minimum restocking/administration charge of 5 + VAT will be made on returned goods.

Returns We want you to be happy with your purchase from Electrex World Limited however there may be certain instances when products may need to be returned.

International Returns

International returns must be marked as 'Return - Failed Sale on any customs documentation. If there are any customs fees to pay, we will deduct these from your refund/credit.


  1. All returns must be accompanied by a copy of the original invoice and a completed returns form which can be downloaded using the following link:
  2. Returns take approximately five business days to process upon receipt of the item.
  3. We are not responsible for the loss or damage of items during their return. Please note that the customer has a duty of care whilst the goods are in their possession and that they should be thoughtfully packaged for the return shipment.
  4. Buyer is responsible for any shipping charges when returning the item.
  5. When fitting electrical parts these can be damaged by the same faulty electrical system that caused the initial failure and in such circumstances these parts cannot be returned for refund.
  6. No refund can be given If the item is out of warranty, if the item is within warranty but has been subjected to conditions beyond their specification or the item has been fitted/used.

Return Address

Electrex World Limited Units 43-46 Vanalloys Business Park Stoke Row Oxfordshire RG9 5QW

2006-2016 Electrex World Ltd. All rights reserved. Home | Terms & Conditions

Registered in England & Wales Company Registration number 04306310. VAT number 785 299 174.

RotorIR2266.00Product link
Ignition StatorEWST-0045-TC00-00CW180.00Product link
CDICD068CE0399.00Product link
HT CoilHT5530.00Product link
SwitchSW1120.00Product link
HT plugcapPLUGCAP4.00Product link
