Bultaco Sherpa Trials, El Bandido, AC only Lighting/Ignition Stator Kit - STK-154L

Bultaco Sherpa Trials, El Bandido,  AC only Lighting/Ignition Stator Kit - STK-154L
Bultaco Sherpa Trials, Al Bandido Lighting/Ignition Stator Kit - (STK-154L)Original Femsatronic rotor detail- (STK-154L)Original Femsatronic rotor reverse- (STK-154L)Stator Kit inc. lighting - view 4- (STK-154L)
Stator Kit inc. lighting - view 5- (STK-154L)AC wiring diagram

Price (excl. vat): 234.00 / 273.78
(280.80 / 328.54 Including VAT at 20%)

Many of these items are made to order.
You will be advised on any delay.

Stator Kit Fits:

Bultaco:El BandidoSherpa Trials
Motobi:Catria Magneto

NOTE: This kit utilises the original Femsatronic flywheel rotor which has 4 magnetic poles. Femsatronic flywheel measurements - : 98.4mm and 4 x magnets instead of 6 - please click on images above.

  • 75w max output at high RPM only.
  • High energy self generating CDI ignition, sparking starts at 150rpm.
  • The spark energy and the timing are produced by the stator coil. The exact advance curve is determined by the stator + CDI combination.
  • Available as 6v or 12v AC (for DC lighting using LED lights with a capacitor or small battery please see STK-153L in related products below). NOTE: AC types are recommended for maximum lighting efficiency and low maintenance as a battery is not fitted.
  • Utilises original Femsatronic rotor which has 4 magnetic poles.
  • Replaces original points sytem with cdi electronic ignition.
  • Electronic advance of 13 degrees is specifically developed to give the Sherpa smooth tractable power, ideal for trials.
  • Very easy to fit and set-up without the need for specialist engineering facilities.
  • High quality electroplating and stainless steel fittings (where possible) used for maximum corrosion protection.
  • IGNITION ONLY ALSO AVAILABLE (STK-154)- see related products below.
  • Manufactured in the UK.
